Solis 110.20

Solis

110.20

Power up Your Productivity with Solis

The Power Of Japanese Technology
With its advanced technology and powerful engine, the Solis S110.20 can easily handle heavy-duty tasks. It also features a comfortable and ergonomic cabin with excellent visibility and easy access to all controls, making it a popular choice for professional farmers.

Solis 110.20ROPS

4 CYLINDER TURBO CHARGED ENGINE

Solis 110.20ROPS

2DA HYDRAULIC CIRCUIT

Solis 110.20ROPS

12+12 SYNCHROMESH SHUTTLE TRANSMISSION

hydraulic-assisted-break

HYDRAULIC ASSISTED BRAKES

Technical Specifications

ENGINE
HP Category 110 HP
No. of Cylinders 4
Displacement cc 4087
Aspiration Turbocharged with Intercooler
Bore/Stroke (mm) 105/118
Rated RPM 2200
Air Cleaner Dry Air Cleaner
Max Torque 430@1300
TRANSMISSION
Drive 4WD
Clutch Double Clutch
Gearbox 12F + 12R
Transmission Synchromesh Shuttle Transmission
SPEED (FORWARD)
Min Speed (km/h) 1.67
Max Speed (km/h) 34.86
Driver Seat Mechanical Suspension
BRAKE
Brakes Wet Disc Brakes
Type of Actuation Hydraulic Assisted Brakes
Hand Brak Mechanical
DIFFERENTIAL LOCK
Differential Lock Mechanical (Foot Operated)
PTO
PTO (RPM) 540/540E
540/100(Optional)
PTO (Actuation) Mechanical
STEERING
Steering Power
ELECTRICAL
Battery 12V, 110Ah
Alternator 12V, 90Amp
Seven Pin Trailer Socket Standard
HYDRAULICS
Position Control Standard
Automatic Draft Control Standard
3 Point Linkage Standard
Lifting Capacity (Kg) 3500
Auxiliary Hydraulic Circuit 2DA
SAFETY SWITCH
Neutral Safety Switch Standard
P.T.O Safety Switch Standard
Clutch Safety Switch Standard
CAPACITY (LTRS)(+/-5%) APPROX
Fuel Tank (Ltr.) 117
TURNING RADIUS IN (m
Without Brakes 6.2
TYRE
Tyres Front: 380/85R24
Rear: 460/85R34
DIMENSION & WEIGHT (+/-5%)
Gross Weight (Kg) 4085
Wheel Base (mm) 2376
Total Length (mm) 4311
Total Width (mm) 2255
Height (mm) upto ROPS 2690
Ground Clearance (mm) min 455
Front Track, (mm), min.-max. 1762
Rear Track, (mm), min.-max 1724
OTHERS
Fuel Indicator Gauge Standard
Registration Plate with Light Standard
Front Tow Hook Standard
Front & Rear Weights 72 Kg Base Weight+ 31*8
Rear – 40×1(Each Wheel)
Drawbar Standard
ROPS Standard
Canopy Optional
Cabin Optional
OPTIONAL FEATURES
Front Mudgaurd Standard
Trailer Brake HTB
Additional Weight Optional
Front 2×31 Kg
Rear 40×1 Each Wheel | 40×2 Each Wheel
